Square Body Needle Valve
GOFLOW Valve & Fittings offers the HBV Series Square Body High Pressure Ball Valves, designed for reliable on-off control in demanding high-pressure applications. These valves feature a 3-piece construction with a square body design, ensuring enhanced strength, durability, and ease of maintenance.
Manufactured using premium materials such as SS 316, Duplex, Monel, Inconel, and Hastelloy, they provide excellent corrosion resistance and long service life in critical environments.
They are available with versatile end connection options including Male & Female NPT, BSPP, BSPT, and Tube End connections, ensuring compatibility with a wide range of systems.
- Size Range: 1/8″ to 1″
- Maximum Working Pressure: Up to 10,000 psig (689 bar)
Features & Options
• Floating ball design ensures leak-proof shut-off under high pressure
• Available in PTFE, Delrin, and PEEK packing materials
• Anti blow-out internally loaded stem for enhanced safety
• Multiple handle options available
• Robust square body construction for high-pressure performance
Testing & Quality Assurance
• 100% Hydrostatic Shell Test: Conducted at 1.5 times the working pressure
• 100% Hydrostatic Seat Test: Conducted at 1.1 times the working pressure
• 100% Pneumatic Seat Testing performed
• All valves are factory tested and certified with a unique serial number
• NACE certification available upon request
• Complete heat code traceability ensured
